The latest addition to the Rotabroach range, the E50 Pivot Magnet is specifically designed for drilling on curved, uneven surfaces. With its permanent magnet, the E50PM retains magnetic adhesion, even on thinner surfaces.
-Maintains strong grip on curved steel and pipework down to 3.5mm material thickness.
-Can be also used for standard flat surface drilling.
-Twist drill, threading and countersinking capability.
-Permanent magnet technology – magnet does not require electrical power.
-Double pivoting magnet base – two separate magnets allowing machine movement in-between drilling for inspection & debris removal without losing position.
-Safe and hidden away internal cabling.
-Mounted coolant bottle, steel sliding guard and switchable handle.
-Centered control panel with Cutsmart™ for increased tool and machine life.
See video of the drill in action here- https://www.youtube.com/watch?v=hsVA_YDEZNM
|Model Number||Element 50/1PM|
|Motor Specification||110V / 1500W|
|No Load rpm||Low Gear: 100-265 RPM / High Gear: 200-500 RPM|
|Maximum hole cutting capacity||ø50 x 50mm Deep – 20mm with 2MT Shank Drill|
Height 490mm Min / 640mm Max
Width 190mm (with capstan)
Length 317mm (with guard)
|Magnetic adhesion||8430N Magnet Size:277mm x 190mm|
Cutsmart2™ Technology / Fixed guard
Magnetic Detection / Secondary motor protection
